Wiśniowski gate controller 24V 140W eLB7Hk2

Description eLB7Hk2 – Gate controller 24V 140W Gate controller 24V 140W eLB7Hk2 This innovative device was designed to ensure reliability and functionality in gate automation systems. Thanks to its advanced technology and robust construction, the eLB7Hk2 controller is ideal for both residential and commercial installations. It is a controller for gate and garage drives using 24V DC motors with a power output of up to 140W. It has a multi-core plug for direct connection connect controller for the ST-1, eL01a, or eL01 connection board. Perfect for continuous operation. It can be used in residential car parks, private properties, and businesses. The eLB7Qk controller is often used as a replacement for the Wiśniowski ST1 or ST2 controller. The drivers are available in four versions: eLB7Qk operating in High Security KeeLoq® mode with a 100 mm cable length eLB7Qk2 operating in High Security KeeLoq® mode with a beam length of 290 mm eLB7Hk with a beam length of 100 mm, works with almost all remote controls compatible with the KeeLoq® coding system eLB7Hk2 with a beam length of 290 mm, works with almost all remote controls compatible with the KeeLoq® coding system Basic features of eLB7k Soft start and stop to increase the life of the gate Built-in radio receiver to allow the controller to operate remote controls Control via transmitters (up to 34) on the 433.92MHz frequency with KeeLoq® dynamically rolling code to increase the remote control's operating range Remote control programming to make coding remote controls easier Bell button control Housing estate function Gate function Infrared barrier to protect the gate against accidental closing Auto-close function Automatic closing of the gate earlier after passing through the infrared barrier to save electricity Adjustment of static and dynamic overload force Automatic overload release Light signaling or switching on with delayed switching off of the lighting Simple installation and programming procedure Technical data: eLB7Qk | eLB7Qk2 | eLB7Hk | eLB7Hk2 Power supply: 24V ac/dc Operating temperature range: -20ºC / 70ºC Fuse type: 6.3 A dimensions (5×20) Motor power: max 140W External dimensions (width x depth x height): 84.8mm x 154.4mm x 42.8mm without cable Housing: splash-proof plastic housing IP40 Weight: 250g | 270g | 250g | 270g Output parameters:     Relay outputs (type, quantity, max. load): DC motor, one, 5.8A/24Vdc (max. power 140W) Lamp relay output (type, quantity, max. load): monostable, one, 1A/24Vac (max. power 25W) Radio parameters:   Radio module: integrated, superheterodyne to ensure high reliability, repeatability and immunity to radio interference Transmission standard: KeeLoq® Range: up to 200m (when using eLdrim transmitters) Modulation type / frequency: OOK / 433.92MHz Antenna input impedance: 50 Ω Antenna: Internal antenna, terminals for connecting an external antenna to the eL01a to extend the remote control range Remote control memory: 34pcs | 34pcs | 48pcs | 48pcs. Functionality:     Auto-close time: 5s – 10min Maximum controller operation time: 120s Maximum lamp lighting time: 25 minutes User interface: simple device installation, learning and configuration procedure, based on one LED and one button to facilitate controller setup Transmitter configuration: ability to assign any button to a channel so that you can assign different functions to the remote control Possibility to erase entire memory: yes Possibility to delete a single remote control: no Possibility to register the remote control without having to access the receiver buttons: yes | yes | no | no Notes: During installation, it is necessary to connect photocells. If there are no photocells, a jumper must be placed on the eL01a connection board. The eLB7Qk is compatible with the ST1 connection board. When installing in place of the ST2 controller, it is REQUIRED to change the connection board to eL01a and change the limit switch configuration to NO. Why choose the eLB7Hk2 controller? The eLB7Hk2 gate controller is an excellent choice for those seeking efficient, safe, and durable gate automation solutions. Its modern features and robust construction guarantee long-term, trouble-free operation, making it an ideal solution for both residential and commercial users. Order now and enjoy reliable control of your gate! Files to download: eLB7Q(H)k(2)—User Manual-Irev1.228.pdf
